| Main Technical Parameters of Short Rod | ||||||||||||
| Wheel Model | Wheel Size | Number of Wheels | Brake Gears | Brake Type | Mounting Method | Screw Length (mm | Swivel Radius (mm | Wheel Disc Width (mm) | Mounting Height (mm) | Load Capacity (kg) | Wheel Tread Materia | Spindle Material |
| TN150C-062- D32X50-3D30 | 150 | Twin-Wheel | 3 gears for caster | Full brake | Screw type | 52.2 | 116±1 | 79士1 | 167士1 | 150 | TPE | SAPH440 metal main board |
| TN150C-062- D32X50-3D-2/30 | 150 | Twin-Wheel | 3 gears with 2 functions | Full brake | Screw type | 52.2 | 116±1 | 79士1 | 167士1 | 150 | TPE | SAPH440 metal main board |
| Main Technical Parameters of Long Rod | ||||||||||||
| Wheel Model | Wheel Size | Number of Wheels | Brake Gears | Brake Type | Mounting Method | Screw Length (mm | Swivel Radius (mm | Wheel Disc Width (mm) | Mounting Height (mm) | Load Capacity (kg) | Wheel Tread Materia | Spindle Material |
| TN150C-062- D28X96-3D30 | 150 | Twin-Wheel | 3 gears for caster | Full brake | Screw type | 96±0.5 | 116±1 | 79士1 | 167士1 | 150 | TPE | SAPH440 metal main board |
| TN150C-062- D28X96-3D-2/30 | 150 | Twin-Wheel | 3 gears with 2 functions | Full brake | Screw type | 96±0.5 | 116±1 | 79士1 | 167士1 | 150 | TPE | SAPH440 metal main board |
| TN150C-062- D28X96-2D45 | 150 | Twin-Wheel | 2 gears for caster | Full brake | Screw type | 96±0.5 | 101.5±1 | 79士1 | 167士1 | 150 | TPE | SAPH440 metal main board |
