| Main Technical Parameters of Short Rod | ||||||||||||
| Wheel Model | Wheel Size | Number of Wheels | Brake Gears | Brake Type | Mounting Method | Screw Length (mm | Swivel Radius (mm | Wheel Disc Width (mm) | Mounting Height (mm) | Load Capacity (kg) | Wheel Tread Materia | Spindle Material |
| Q200C-WG- D32X50-3D_2-30 | 200 | Single Wheel | 3 gears with 2 functions | Full brake | Screw type | 49.5 | 160±1 | 70±1 | 230±1 | 200 | TPU | / |
| Q200C-WG- D32X50-3D30 | 200 | Single Wheel | 3 gears for caster | Full brake | Screw type | 49.5 | 160±1 | 70±1 | 230±1 | 200 | TPU | / |
| Q200C-WG- D32X50-2D30 | 200 | Single Wheel | 2 gears for caster | Full brake | Screw type | 49±0.5 | 160±1 | 70±1 | 230±1 | 200 | TPU | / |
| Main Technical Parameters of Long Rod | ||||||||||||
| Wheel Model | Wheel Size | Number of Wheels | Brake Gears | Brake Type | Mounting Method | Screw Length (mm | Swivel Radius (mm | Wheel Disc Width (mm) | Mounting Height (mm) | Load Capacity (kg) | Wheel Tread Materia | Spindle Material |
| Q200C-WG- D28X96-3D_2-30 | 200 | Single Wheel | 3 gears with 2 functions | Full brake | Screw type | 95.5 | 160±1 | 70±0.6 | 228±1 | 200 | TPU | Auminum alloy |
| Q200C-WG- D28X96-3D30 | 200 | Single Wheel | 3 gears for caster | Full brake | Screw type | 95.5 | 160±1 | 70±0.6 | 228±1 | 200 | TPU | Auminum alloy |
| Q200C-WG- D28X96-2D30 | 200 | Single Wheel | 2 gears for caster | Full brake | Screw type | 96±1 | 160±1 | 70±1 | 228±1 | 200 | TPU | Auminum alloy |
