| Main Technical Parameters of Short Rod | ||||||||||||
| Wheel Model | Wheel Size | Number of Wheels | Brake Gears | Brake Type | Mounting Method | Screw Length (mm | Swivel Radius (mm | Wheel Disc Width (mm) | Mounting Height (mm) | Load Capacity (kg) | Wheel Tread Materia | Spindle Material |
| A-200C-WG- D32X50-3D30 | 200 | Single Wheel | 3 gears for caster | Full brake | Screw type | 32±0.5 | 154±1 | 67±1 | 229±1 | 200 | TPU | Auminum alloy |
| A-200C-WG- D32X50-3D-2/30 | 200 | Single Wheel | 3 gears with 2 functions | Full brake | Screw type | 32±0.5 | 154±1 | 67±1 | 229±1 | 200 | TPU | Auminum alloy |
| Main Technical Parameters of Long Rod | ||||||||||||
| Wheel Model | Wheel Size | Number of Wheels | Brake Gears | Brake Type | Mounting Method | Screw Length (mm | Swivel Radius (mm | Wheel Disc Width (mm) | Mounting Height (mm) | Load Capacity (kg) | Wheel Tread Materia | Spindle Material |
| A200C-WG- D28X96-3D30 | 200 | Single Wheel | 3 gears for caster | Full brake | Screw type | 96±0.5 | 154±1 | 67±1 | 229±1 | 200 | TPU | Auminum alloy |
| A200C-WG- D28X96-3D-2/30 | 200 | Single Wheel | 3 gears with 2 functions | Full brake | Screw type | 96±0.5 | 154±1 | 67±1 | 229±1 | 200 | TPU | Auminum alloy |
| A200C-WG- D28X96-2D45 | 200 | Single Wheel | 2 gears for caster | Full brake | Screw type | 96±0.5 | 154±1 | 67±1 | 229±1 | 200 | TPU | Auminum alloy |
